Challenge
Whilst drilling through the curve in an unconventional well in Midland, Texas, USA, the operator was unable to achieve sufficient mud column height to enable drilling operations to continue. An approximate 1,200ft (366m) long solution was required to maximize well bore ID and continue normal drilling operations.
Solution & Achievement
Coretrax Global were called to run a 7 5/8” x 9 5/8” 40# Expandable Drilling Liner (Coretrax DL) outside the 9 5/8” shoe to stabilize the hole and isolate the problematic zone to allow drilling operations to continue.
Upon successful running and testing of the expandable system, the operator was able to regain the capability to run their desired liner size out into the horizontal open hole section.
Note: With premium expandable connections, up to 4,000ft of Coretrax Drilling liner can be run and expanded.
The continuous 1,146 ft expandable liner was successfully deployed and tested from 9,399ft to 10,545ft, and whilst running the drilling liner, the cement was properly displaced and a cement dart seated in shoe. The Coretrax drilling liner was then successfully expanded to achieve an ID of 7.967” and the running tools pulled out of the hole.
